Elster AMCO Water
Flowmeters
Cold water meter – positive displacement (Discontinued)
Elster AMCO Water’s C700 oscillating piston type water meters are the most advanced design positive displacement meters available. Boasting dependability and engineering excellence, the C700 line, sizes 5/8” to 2”, can be offered with a variety of registers, pulsers and material configurations, including a choice of waterworks or NSF-61 certified low-lead bronze main cases. These meters are appropriate for applications in direct read, pulse output, batching and rate of flow for plant maintenance.
Downloads:
- C700 5/8″ Download
- C700 3/4″ Download
- C700 1″ Download
- C700 1 1/2″ and 2″ Download
- C700 polymer Download
- Digital register C700 Download
Cold water meter – Commercial (Discontinued)
Elster AMCO Water turbine meters and compound meters provide long-life, high accuracy measurement for high volume services.
Downloads:
M190 Hot water meter
The M190 is a multijet (inferential) impeller meter. The only moving parts in the measuring chamber are the impeller and magnet. The impeller movement is transferred by a magnetic coupling to the hermetically sealed register, which can be turned to any position for easy reading.
Downloads:
Oil meter
For measurement of a wide viscosity range, including light, medium and even heavy heating oil and diesel oil, the Elster AMCO Water line offers oil meters from 1/8” through 2”, covering flows from ¼ to 8000 gph with accuracy ± 1%.
Downloads:
V100
The V100 (formerly PSM190) meter is a positive displacement type meter operating on the oscillating piston principle. For use with POTABLE COLD WATER up to 120° F (50° C) and working pressures up to 150 psi. Available in low lead bronze and polymer and with or without a pulse output.
Downloads: Elster V100-110
T210 – OBSOLETE
The T210 provides accurate remote readings for digital/pulse registers while adding convenience and safety for the reader.
Downloads: Brochure
