NIAGARA


6600 series flowmeter6600 Series Magnetic Flowmeter

Ease of Installation & Maintenance: Grounding rings not required, No moving parts.

High accuracy: +/- 0.5% of flow rate; Independent of fluid viscosity, density, temperature, or solids content.

Does not affect Process Conditions: Negligible pressure drop across flowmeter.

Downloads: Brochure | Manual


mtx turbine flowmeterMTX Turbine Flowmeters – Obsolete – SEE ELSTER M190

Versatile – Models 122 & 123 display continuous totalization

– Models 413, 433, & 444 display continuous totalization and provide a calibrated contact closure

– Models 420 & 421 display continuous totalization with the option of adding the 840 calibrated contact closure and/or the 860 calibrated digital pulse signal without removing the flowmeter from the line.

Durable

          • Sealed register prevents condensation or fogging
          • One internal moving part
          • Multi-jet design ensures balanced forces and extends meter life

Downloads: Brochure | Manual


wpx turbine flowmeterWPX Turbine Flowmeters

Durable, Reliable, Saves Space:
The WPX Turbine offers accurate flow measurement in a very compact size. A sealed register prevents condensation or fogging. Modular construction allows ease of service and field repair. This meter operates with only one moving part in contact with the fluid. Pulse transmitters can be installed easily and without downtime.

Model 840 Pulser provides a calibrated contact closure

Model 860 Pulser provides a calibrated digital pulse signal

Downloads: Brochure | Manual


Force_MeterForce Meter

The ForceMeter™ offers the same rugged design for which the Niagara Meters brand is known. The ForceMeter™ is ideal for applications including water, compressed air, gases, super-heated steam and saturated steam. Available as either an Insertion type or Inline meter with 4 standard mounting options.

Downloads: Brochure | Manual


nutating disc meterNutating Disc Meter

Liquid enters a precision-machined chamber containing a disc which nutates (wobbles). The position of the disc divides the chamber into compartments containing an exact volume. Liquid pressure drives the disc to wobble and a roller cam causes the nutating disc to make a complete cycle. The compartments are filled and emptied each cycle. The movements of the disc are transmitted by a gear train to a register/totalizer or pulse transmitter. Close clearances between the disc and chamber ensure minimum leakage for accurate and repeatable measurement of each volume cycle.

Downloads: Brochure | Manual


piston meterOscillating Piston Meter

Liquid enters a precision-machined chamber containing an oscillating (rotating) piston. The position of the piston divides the chamber into compartments containing an exact volume. Liquid pressure drives the piston to oscillate and rotate its center hub. The movements of the hub are sensed through the meter cover by a follower magnet. Each revolution of the piston hub is equivalent to a fixed volume of fluid, which is indicated as flow by a register/totalizer. Close clearances between the piston and the chamber ensure minimum liquid slip for highly accurate and repeatable measurement of each volume cycle.

Downloads: Brochure | Manual


model 3030Model 3030 Batch Controller   –  OBSOLETE

The Model 3030 is a microprocessor based batch controller and flow rate indicator/totalizer that is capable of single or dual stage batch control. Two process parameters such as batch count and final batch quantity can be displayed simultaneously on the 16-character display. The Model 3030 has five control inputs, which when switched to ground, perform specific functions such as remote batch stop. Four open collector control outputs may be used to interface with remote devices such as relays, counters, and lights.

Downloads: brochure | manual


BC_IMGModel BC

The BC Flow Computer satisfies the instrument requirements for a variety of flowmeter types in liquid applications. Multiple equations and instrument functions are available in a single unit with many advanced features. Single key direct access to measurements and display scrolling is supported. The isolated analog output can be chosen to follow volume flow, corrected volume flow, mass flow, temperature, or density by means of a menu selection. Remote metering software available.

Downloads: Brochure | Manual | Wiring


model 1530A indicatorModel 1030 Indicator   –  OBSOLETE

The Model 1030F is a microprocessor based flow rate indicator/totalizer with a 4-20 mA output that is proportional to flow rate and RS-485 communications. Flow rate and total can be displayed simultaneously on the 16-character display. The Model 1030F has five control inputs, which when switched to ground, perform specific functions such as resetting the totalizer. Four open collector control outputs may be used to interface with remote devices such as relays, counters, and lights.

Downloads: brochure | manual


FC_IMGModel FC

The FC Flow Computer satisfies the instrument requirements for a variety of flowmeter types in liquid, gas, steam and heat applications. Multiple flow equations are available in a single instrument with many advanced features. Includes equations for most flow meter types. The alphanumeric display offers measured parameters in easy to understand format.

Downloads: Brochure | Manual | Wiring


model 1005 pulse to dcModel 1005 Pulse to DC Converter

The Model 1005 amplifies and conditions the contact closure or digital pulse signal from most flowmeters and converts it to a powered 4-20 mA output. The 4-20 mA signal is proportional to flow rate and can be used to interface with chart recorders, computers, or other instrumentation. The Model 1005 is factory calibrated with 4 mA set at zero flow and 20 mA set at a customer specified flow rate.

Downloads: Brochure | Manual


5600 series controllerUltrasonic Liquid Level Controller – 5600 Series

Quick Configuation – Adjust systems parameters and pre-calibrates unit without special software.

Continuous Non-Contact Level Measurement – No contamination of material. No lost parts or cables.

Sentry™ DSP – Provides stable and accurate reading under noisy process conditions.

Built-in Optically Isolated Serial Port – Versatile interfacing for data collection, servicing, and building large multi-vessel communications systems.

NEMA-4X Enclosure – FRP or optional stainless steel offers the right protection for your environment.

Downloads: Controller BrochureTransducer BrochureFloat Switch Brochure | Manual
